Garnet

Garnet

Garnet is considered one of the best water filter media due to its ability to achieve high filtration rates and longer durability. It serves as an efficient support bed in backwashing filters for high-density media and is used as the lower filtration layer. Its high density facilitates effective filter design and ensures stability in the media. Additionally, garnet sand has a high specific gravity, making it an ideal lower layer. With its size, it can effectively filter particles in the range of 10-20 microns.

Benefits of Garnet

Applications

Garnet Sand is widely used in various industries, including:

High-pressure water jet cutting n

Sand blasting

Filtration industry

Sandpaper production

About Best Garnet

Size Tables

Garnet Sand is available in various mesh sizes:

Millimetres ScaleASTM Scale
0.15 mm100+ Mesh
0.12-0.18 mm80-120 Mesh
0.5-0.25 mm30-60 Mesh
0.7-0.35 mm20-40 Mesh
1.7-0.7 mm10-20 Mesh

Grades of Garnet Sand

Garnet Sand sizes typically range from 1.2mm to 0.08mm in diameter. We manufacture Garnet based on ASTM Mesh Sizes to meet client needs.

Coarse Garnet Media

Fine Garnet Media

Filtering Garnet Sand

Chemical Analysis

Chemical PropertyPercentage (%)
SiO2 (no free silica)35.00%
Fe2O333.00%
Al2O323.00%
MgO7.00%
MnO1.00%
CaO1.00%
